AK10 930126104
| product description: | Bestellnummer: 930 126-104 |
| description: | Insulated alligator clip. Clamping range up to 6 mm bolt diameter. Fine wire section for very thin wires. Only the lower part o fthe clip has a tin-plated, brass contact insert. 4 mm diameter socket connection. |
| typ: | AK 10 gruen/green |
| system: | 4 mm system |
| order number: | 930 126-104 |
| clamping range: | 6 mm |
| color versions: |  |
| technical data | |
| type of contact: | clamp |
| type of termination: | 4 mm socket (unsprung) |
| rated voltage: | 30 VAC / 60 VDC |
| rated current: | 6 A |
| contact resistance: | 15 mOhm |
| material | |
| contact material: | brass |
| contact surface material: | tin |
| housing material: | PS |
| environmental conditions: | |
| temperature range: | -25 °C to +60 °C |
| inflammable class: | |
| housing: | UL 94 HB |
| drawing | |
| |  |
