| AC A | | 600.0/1000A (Auto-ranging) |  | | ±1.5%rdg±4dgt | [45 - 65Hz] | | ±2.0%rdg±4dgt | [40 - 400Hz] |
|
| AC V | | 600.0V | | | ±1.2%rdg±3dgt | [45 - 65Hz] | | ±1.5%rdg±4dgt | [40 - 400Hz] |
|
| DC V | | 600.0V | | | ±1.2%rdg±3dgt | |
|
| Ω | | 600.0Ω/6.000kΩ (Auto-ranging) | | | ±1.3%rdg±5dgt | (600Ω) | | ±2.0%rdg±3dgt | (6.000kΩ) |
|
| Continuity buzzer | 600Ω (Buzzer sounds below 90Ω) |
| Conductor size | φ33mm max. |
| Applicable standards | IEC 61010-1 CAT IV 300V, CAT III 600V Pollution degree 2
IEC 61010-031, IEC 61010-2-032, IEC 61010-2-033,
IEC 61326-2-2, IEC 60529, EN 50581 (RoHS) |
| Power source | R03/LR03 (AAA) (1.5V) × 2 |
| Continuous measuring time | Approx.170 hours (when R03 is used)
(Auto power save : approx. 10 minutes) |
| Dimensions | 204(L) × 81(W) × 36(D)mm |
| Weight | 220g Approx. (including batteries) |
| Accessories | 7066A (Test leads), 9079 (Carrying case), R03 (AAA) × 2,
Instruction Manual |
| Optional | 8008 (Multi-Tran) |
