CSB Battery 12V 34AH CSB - Model : GP12340
GP12340 : 12 V 34 Ah
GP 12340 is a general purpose battery up to 5 years in standby service.
As with all CSB batteries, all are rechargeable, highly efficient, leak proof and maintenance free.
Download
Specification
Cells Per Unit | 6 |
Voltage Per Unit | 12 V |
Capacity | 34 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F) |
Weight | Approx. 10.48kg. (23.10 lbs.) |
Maximum Discharge current | 380A (5sec.) |
Internal Resistance | Approx. 9.5 mΩ |
Operating Temperature Range | Discharge：-15℃~50℃(5°F~122°F) |
Charge：-15℃~40℃(5°F~104°F) | |
Storage：-15℃~40℃(5°F~104°F) | |
Nominal Operating Temperature Range | 25°C ± 3°C (77°F± 5°F) |
Float charging voltage | 13.5 to 13.8 VDC/unit Average at 25°C (77°F) |
Recommended Maximum Charging current limit | 10.2A |
Equalization and Cycle Service | 14.4 to 15.0 VDC/unit Average at 25°C (77°F) |
Self Discharge | It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃ |
Terminal | B5-L terminal to accept M6 nut & bolt |
Container Material | ABS(UL94-HB) & Flammability resistance of(UL94-V0) can be available upon request. |
